Basic Info.
Model NO.
YSB-15
Rotary Table
T or D Type
Rotary Speed Regulation
Inverter Stepless
Positioner Turning Method
Hydraulic
Lifting Method
Hydraulic
Control Way
Main Control Cabinet and Manual Box Control
Exported to
Brazil.France,Italy,Greece,Poland,etc
Rotate Speed
0.1-1.2rpm
Worktable Diameter
1000mm or Customized
Arm Lifting up Range
0-45 Degree
Control Box Cable Length
5m-10m
Machine Weight
1.5t
Filting Range
0-135 Degree
Input Voltage
Customized
Trademark
Lemar
Origin
Wuxi, China
HS Code
8428909090
Production Capacity
100 PCS/Year
Product Description
Hydraulic lift positioner is mainly used for welding large-sized structural parts.
This is a 3-axis welding positioner, which can realize the three functions of hydraulic lifting, flipping and rotating the welding work-piece.
Through the rotation and turning of the worktable, the work-piece is placed in the best welding or assembly position, which can effectively improve the welding quality, reduce the number of work handling, reduce the labor intensity of workers, and improve labor efficiency.
The rotary table of the hydraulic lift positioner is machined with radial "D" grooves for fixing the workpiece;
This is a 3-axis welding positioner, which can realize the three functions of hydraulic lifting, flipping and rotating the welding work-piece.
Through the rotation and turning of the worktable, the work-piece is placed in the best welding or assembly position, which can effectively improve the welding quality, reduce the number of work handling, reduce the labor intensity of workers, and improve labor efficiency.
The rotary table of the hydraulic lift positioner is machined with radial "D" grooves for fixing the workpiece;
Machine details:
| No. | Item | YSB-15T |
| 1 | Rated load | 15T |
| 2 | Rotation speed of worktable | 0.05-0.5rpm |
| 3 | Table rotation mode | frequency conversion stepless speed regulation |
| 4 | Turning angle of worktable | 0-130° |
| 5 | Workbench turning method | hydraulic turning |
| 6 | Max center of gravity distance | 400mm |
| 7 | Maximum eccentricity | 200mm |
| 8 | Lifting stroke of worktable | 1338mm |
| 9 | Hydraulic system pressure | 21mpa |
| 10 | Diameter of worktable | φ2200mm |
Features of each part:
1. The rotation adopts the stepless speed regulation of the frequency converter, which makes the speed regulation range of the hydraulic lifting welding positioner wider and the operation more stable;
2. The worktable of the automatic welding positioner adopts hydraulic turning and lifting, which has high efficiency and stable operation;
The hydraulic system has the function of pressure relief and self-protection, which can effectively prevent mechanical overload from damaging the equipment; the structure is compact, the floor space is small, and the operation is more convenient;
3. The hydraulic lifting automatic welding positioner does not need to be fixed on the foundation and is easy to move;
4. The main control cabinet and the manual control box control, the manual control box can be used to operate the equipment at different positions of the equipment.
1. The rotation adopts the stepless speed regulation of the frequency converter, which makes the speed regulation range of the hydraulic lifting welding positioner wider and the operation more stable;
2. The worktable of the automatic welding positioner adopts hydraulic turning and lifting, which has high efficiency and stable operation;
The hydraulic system has the function of pressure relief and self-protection, which can effectively prevent mechanical overload from damaging the equipment; the structure is compact, the floor space is small, and the operation is more convenient;
3. The hydraulic lifting automatic welding positioner does not need to be fixed on the foundation and is easy to move;
4. The main control cabinet and the manual control box control, the manual control box can be used to operate the equipment at different positions of the equipment.
