Basic Info.
Model NO.
BWJ-10
Max Eccentricity Distance
150mm
Tilting Angle
0-90°
Voltage
380V
Condition
New
Function
Pipe Flange Welding Turning Table
Control Mode
Normal or CNC
Horizontal Loading Weight
1000kg
Vertical Loading Weight
500kg
Rotation Speed
0.05-0.5rpm
Tilting Motor
1.1kw
Worktable Diameter
1200mm
Rotation Motor
1.1kw
Speed Mode
AC Frequency
Colour
Customized
Exported to
USA,UK,Canada,Greece,Poland,Brazil,South Africa
Lead Time
5 Days
Pedal Switch
Yes
Optional
TIG MIG Mag Welding Machine
Postioner Type
Seat Type
Trademark
Lemar
Origin
Wuxi, China
HS Code
8428909090
Production Capacity
3000PCS/Year
Packaging & Delivery
Package Size
90.00cm * 110.00cm * 110.00cm
Package Gross Weight
400.000kg
Product Description
What is an automatic welding positioner?
The welding positioner can turn and drag the welding seam of the pipe and the flange to the ideal welding position to improve the welding accuracy.
The stage does not come with self-locking ability to move during tilt rotation; the tilt limit position is controlled by limit switches.
There are many types of welding positioners.
The more common ones in the market are seat type welding positioner, double-seat welding positioner, outrigger welding positioner, three-axis welding positioner, etc., which can be applied to different types of welding positioners. field.
The welding positioner can be equipped with welding machine power sources such as argon arc welding machine, MIG welding machine, plasma welding machine to form an automatic welding system. It can be used in manual welding, semi-automatic welding and fully automatic welding.
Common and practical welding auxiliary equipment.
The welding positioner can turn and drag the welding seam of the pipe and the flange to the ideal welding position to improve the welding accuracy.
The stage does not come with self-locking ability to move during tilt rotation; the tilt limit position is controlled by limit switches.
There are many types of welding positioners.
The more common ones in the market are seat type welding positioner, double-seat welding positioner, outrigger welding positioner, three-axis welding positioner, etc., which can be applied to different types of welding positioners. field.
The welding positioner can be equipped with welding machine power sources such as argon arc welding machine, MIG welding machine, plasma welding machine to form an automatic welding system. It can be used in manual welding, semi-automatic welding and fully automatic welding.
Common and practical welding auxiliary equipment.
Specifications:
| Model | Max loading Kg | Worktable diameter mm | Table rotation speed r/min | Table turning speed r/min | Allowable center of gravity X mm | Allowable eccentricity Y mm | Rotary motor(kw) | Flip motor (kw) | Table height mm |
| BWJ-10 | 1000 | 1000-1200 | 0.05-0.5 | 0.4r/min | 200 | 200 | 1.1 | 1.1 | Customized |
Features of welding positioner:
1. The frequency converter is used for stepless speed regulation, which has a wide speed regulation range, high precision and large starting torque.
It can be adjusted according to specific welding needs. It can be used with a welding robot to increase the welding speed while stabilizing the welding quality and effectively improving the welding accuracy.
2. The specially designed groove-type steel core rubber surface roller has large friction force and long service life.
It can clamp welding parts of different specifications, and can flexibly turn over within the load capacity range without safety accidents.
1. The frequency converter is used for stepless speed regulation, which has a wide speed regulation range, high precision and large starting torque.
It can be adjusted according to specific welding needs. It can be used with a welding robot to increase the welding speed while stabilizing the welding quality and effectively improving the welding accuracy.
2. The specially designed groove-type steel core rubber surface roller has large friction force and long service life.
It can clamp welding parts of different specifications, and can flexibly turn over within the load capacity range without safety accidents.
3. Combined box-type base, with high rigidity and strong bearing capacity.
4. The welding positioner has an independent system and drive device, which can coordinate movement with the welding robot during welding.
The automation level of automatic welding positioner turning table is high. The worker only needs to stand on the assembly station, which reduces the labor intensity.
5. With powerful manufacturing process, the straightness and parallelism of each shaft hole are good, and the amount of workpiece movement caused by insufficient manufacturing accuracy is reduced.
4. The welding positioner has an independent system and drive device, which can coordinate movement with the welding robot during welding.
The automation level of automatic welding positioner turning table is high. The worker only needs to stand on the assembly station, which reduces the labor intensity.
5. With powerful manufacturing process, the straightness and parallelism of each shaft hole are good, and the amount of workpiece movement caused by insufficient manufacturing accuracy is reduced.
