Basic Info.
Model NO.
HGK TYPE WELDING ROTATORS
Production Capacity
200 Set /Month
Product Description
SIECC range of welding rotators/tank turning rolls offer the most comprehensive range of any manufacturer all available for sale or rental.
Our range includes pipe rotators from 1 tonne up to 10 tonnes, heavier duty welding rotators up to 1000 tonnes capable of rotating vessels up to 10 metres in diameter.
Whether you require the need to position and weld a small pipe section, flange or elbow, a large pressure vessel or a complex windtower or double jointing line, SIECC has the solution to rotate and position your workpiece to maximise your production efficiency and guarantee to solve your welding and handling requirements.
To best advise you on the options available to discuss your project with our experienced engineering team. They will advise on the welding rotators/tank turning rolls best suited for your application and offer a cost effective sale, rental or rent to own plan to provide maximum flexibility.
Welding rotators - 'what you want, when you need it'.
The HGK type welding rotators have advantages of the same kinds of products in domestic and international.We design and make them according to the requirments of the pressure ve-ssel factory.These products are applied in the handling and automatic welding of the metal circle containers,They have many advantages such as advanced technology,dependabe quality,easy operation.
All rotators have passed the CE,they are used for oil industry,press vessel,wind tower production line,Pipe line production and any other round workpiece.
Welding turn roller are exported to Brazil,India,Jordan,South Africa,UK,Poland,Spain, and so on.
The rotators have two kinds,adjustable and conventional,It can used in all kind of the diameter,and frequency conversion setting,low sound,work placidity.
Our range includes pipe rotators from 1 tonne up to 10 tonnes, heavier duty welding rotators up to 1000 tonnes capable of rotating vessels up to 10 metres in diameter.
Whether you require the need to position and weld a small pipe section, flange or elbow, a large pressure vessel or a complex windtower or double jointing line, SIECC has the solution to rotate and position your workpiece to maximise your production efficiency and guarantee to solve your welding and handling requirements.
To best advise you on the options available to discuss your project with our experienced engineering team. They will advise on the welding rotators/tank turning rolls best suited for your application and offer a cost effective sale, rental or rent to own plan to provide maximum flexibility.
Welding rotators - 'what you want, when you need it'.
The HGK type welding rotators have advantages of the same kinds of products in domestic and international.We design and make them according to the requirments of the pressure ve-ssel factory.These products are applied in the handling and automatic welding of the metal circle containers,They have many advantages such as advanced technology,dependabe quality,easy operation.
All rotators have passed the CE,they are used for oil industry,press vessel,wind tower production line,Pipe line production and any other round workpiece.
Welding turn roller are exported to Brazil,India,Jordan,South Africa,UK,Poland,Spain, and so on.
The rotators have two kinds,adjustable and conventional,It can used in all kind of the diameter,and frequency conversion setting,low sound,work placidity.
| Type | HGK-2 | HGK-5 | HGK-10 | HGK-20 | HGK-40 | HGK-60 | HGK-100 | HGK-200 | HGK-300 | HGK-500 | |
| Load | 2 | 5 | 10 | 20 | 40 | 60 | 100 | 200 | 300 | 500 | |
| Wheel diameter(mm) | 250 | 250 | 300 | 350 | 450 | 500 | 550 | 700 | 800 | 900 | |
| Wheel width(mm) | 100 | 160 | 196 | 210 | 220 | 200(metal) | 220(metal) | 300(metal) | 300(metal) | 300(metal) | |
| Vessel diameter | MIN(mm) | 150 | 250 | 300 | 500 | 500 | 500 | 800 | 800 | 1000 | 1000 |
| MAX(mm) | 2000 | 2800 | 3200 | 4500 | 4800 | 5000 | 5000 | 5000 | 6000 | 8000 | |
| Wheel velocity(m/h) | 6-60 | 6-60 | 6-60 | 6-60 | 6-60 | 6-60 | 6-60 | 6-60 | 6-60 | 6-60 | |
| Power of motor(kw) | 2*0.18 | 2*0.37 | 2*0.55 | 2*1.1 | 2*1.5 | 2*2.2 | 2*3 | 2*4 | 2*5.5 | 2*7.5 | |
