Basic Info.
Product Description
Product specification
The specification of LTMG Diesel Forklift Truck 3 Ton | ||||||
Model | UNIT | FD30 | FD35 | |||
Performance | Power Unit | Diesel | Diesel | |||
Operator Type | Driver/seat | Driver/seat | ||||
Rated Capacity | Kg | 3000 | 3500 | |||
Load Center | mm | 500 | 500 | |||
Max. Lifting Height | mm | 3000 | 3000 | |||
Mast Tilting Angle (Fwd/Bwd) | Deg | 6/12 | 6/12 | |||
Free Lift Height | mm | 145 | 150 | |||
Turning Radius | mm | 2395 | 2415 | |||
Lifting Speed (Loaded/Unloaded) | mm/s | 480/500 | 400/450 | |||
Lowering Speed (Loaded/Unloaded) | mm/s | 420/400 | 400/370 | |||
Travelling Speed (Loaded/Unloaded) | Km/h | 20/21 | 20/21 | |||
Max. Gradeability (Loaded) | % | 21 | 21 | |||
Max. Drawbar Pull (Loaded) | N | 17 | 17 | |||
Dimensions | Overall length (without fork) | mm | 2730 | 2770 | ||
Overall Width | mm | 1220 | 1220 | |||
Overhead Guard Height | mm | 2145 | 2145 | |||
Fork Size (LxWxT) | mm | 1070X125X45 | 1070X125X45 | |||
Mast Height (Fork lowered) | mm | 2095 | 2175 | |||
Truck Weight | Kg | 4250 | 4500 | |||
Tyre Size (Front/Rear) | 28×9-15-14PR/6.5-10-10PR | 28×9-15-14PR/6.5-10-10PR | ||||
Engine | Brand | ISUZU | XINCHAI | ISUZU | XINCHAI | |
Model | C240 | C490 | 4JG2 | C495 | ||
Rated Power | Kw/rpm | 35.4/2500 | 35.4/2500 | 40/2650 | 42/2650 | |
Rated torque | N-m/rpm | 137.7/1800 | 160/1600 | 186/1800 | 174/1600 | |
Number of cylinder | 4 | 4 | 4 | 4 | ||
Displacement | 2.36 | 2.67 | 3.06 | 2.8 |
Product Features:
-Adopt TCM type transmission, steering axle
- Isuze engine and Mitsubishi engine are optional
-Equipped with famous brand parts, like Shimadzu pump and valve, Eaton pipe, Nok hydraulic cylinder seals, Toyota seat with safety belt, cooper tank and so on
-Attachments can be equipped as customer's requirements, such as paper roll, forklift rotator, clamp etc.
The most reasonable system matching after repeated verification
After 400 hours of continuous enhancement test
Adopt gradeability improving style transmission, compare with other models
Load sensing priority steering hydraulic system is adopted to reduce pressure loss of hydraulic system
Our Factory
Our customers
Our LTMG Forklift is widely used in the port, wharf, industrial and mining enterprises, station, warehouse, and others.
The quality of our LTMG forklift has been recognized by our customers.
After sales service
LTMG always treat after-sale service as important as sale. Nowadays more than 50 agents around the world can supply LTMG professional after-sale service.
All the product of LTMG supplied with one year or 2000 working hours (which occurs first) period quality warranty.
Detail clauses and policies please check our website and product certificate.
