Basic Info.
Model NO.
PPAWW-3
Frequency Range
Intermediate Frequency
Electric Current
DC
Pipe Diameter Applicable
Dn50-1500
Pipe Wall Thickness Applicable
5-60mm
Materials Applicable
Carbon Steel, Alloy Steel, Stainless Steel and Cry
Welding Line Applicable
Various Welding Lines of Spool Pieces Such as Pipe
Driving System
Pipe Welding Positioner Is Adopted, Clamped Pipe B
Trolley System
a Welding System Is Fixed on The Arm of The Trolle
Counterweight System
No Counterweight
Adjustment Mode
with Electric Cross Regulator
Type
MIG Welders
Transport Package
Sea Worthy Packing
Specification
PPAWM-16Aa
Trademark
QSPT
Origin
China
Production Capacity
30sets/Per Month
Packaging & Delivery
Package Size
300.00cm * 200.00cm * 300.00cm
Package Gross Weight
1000.000kg
Product Description
Performance features
Ø On-line Performance: Designed completely as per the on line equipment of the production line
Ø Application: broad (pipe and cover welding of various structures of DN≥50 in various industries).
Ø Welding Capacity: Excellent (200-400 inch/day, which is 4 times higher than the manual welding)
Ø Operability: very good (applicable and easy to operate even if you are a new user within a short period of time)
Ø Surface finishing: good (the welding gun will always be positioned in the optimum position)
Ø Welding qualification rate: 98% min (without re-working for the skilled operator).
Ø Driving reliability: extremely good (mechanical clamping for the position changing of the pipe welding and forceful driving).
u Technical parameters
Ø Pipe diameter applicable: DN50-600 (φ60-630); DN200-800 (219-830); DN400-1000 (φ406-1016); DN600-1200 (φ610-1219); DN800-1500 (φ813-1524) ;Or custom made acc. to requirements.
Ø Pipe wall thickness applicable: 5-60mm (MIG+SAW or TIG+SAW)
Ø Materials applicable: carbon steel, alloy steel, stainless steel and cryogenic steel, etc.
Ø Welding line applicable: various welding lines of spool pieces such as pipe-pipe, pipe-elbow, pipe-flange, flange-flange and flange-elbow, etc.
Ø Driving System: pipe welding positioner is adopted, clamped pipe by 2 (or 3, 4) jaw chuck & drive it by positioner directly
Ø Trolley system: a welding system is fixed on the arm of the trolley which can move along the track according to the welding location .
Ø Bracket System: Separate type of trolley matching for welding machine, which may be adjusted along the track according to the length of the pipeline.
Ø Counterweight System: no Counterweight
Ø Speed-regulation Mode: VF stepless speed control system
Ø Adjustment Mode: with electric cross regulator
Ø Control system: a product of our patented technology, PLC control with touch screen.
Ø Welding procedure: MIG+SAW or TIG+SAW or TIG+MIG for root pass, fill in & final welding;
Ø Welding Power: With Lincoln Welding Power Source (or as per customers' demands)
Ø On-line Performance: Designed completely as per the on line equipment of the production line
Ø Application: broad (pipe and cover welding of various structures of DN≥50 in various industries).
Ø Welding Capacity: Excellent (200-400 inch/day, which is 4 times higher than the manual welding)
Ø Operability: very good (applicable and easy to operate even if you are a new user within a short period of time)
Ø Surface finishing: good (the welding gun will always be positioned in the optimum position)
Ø Welding qualification rate: 98% min (without re-working for the skilled operator).
Ø Driving reliability: extremely good (mechanical clamping for the position changing of the pipe welding and forceful driving).
u Technical parameters
Ø Pipe diameter applicable: DN50-600 (φ60-630); DN200-800 (219-830); DN400-1000 (φ406-1016); DN600-1200 (φ610-1219); DN800-1500 (φ813-1524) ;Or custom made acc. to requirements.
Ø Pipe wall thickness applicable: 5-60mm (MIG+SAW or TIG+SAW)
Ø Materials applicable: carbon steel, alloy steel, stainless steel and cryogenic steel, etc.
Ø Welding line applicable: various welding lines of spool pieces such as pipe-pipe, pipe-elbow, pipe-flange, flange-flange and flange-elbow, etc.
Ø Driving System: pipe welding positioner is adopted, clamped pipe by 2 (or 3, 4) jaw chuck & drive it by positioner directly
Ø Trolley system: a welding system is fixed on the arm of the trolley which can move along the track according to the welding location .
Ø Bracket System: Separate type of trolley matching for welding machine, which may be adjusted along the track according to the length of the pipeline.
Ø Counterweight System: no Counterweight
Ø Speed-regulation Mode: VF stepless speed control system
Ø Adjustment Mode: with electric cross regulator
Ø Control system: a product of our patented technology, PLC control with touch screen.
Ø Welding procedure: MIG+SAW or TIG+SAW or TIG+MIG for root pass, fill in & final welding;
Ø Welding Power: With Lincoln Welding Power Source (or as per customers' demands)
