Basic Info.
Model NO.
FD50
Fuel
Diesel
Load center
>500mm
Lift height
3000~5000mm
Condition
New
Engine Brand
China Xichai/Japan
Side Shift
Optional
Transmission
Auto Hydraulic
Mast
2 Stage /3 Stage
Lifting Height
3-7m
Color
Red/Yellow/Green
Tyre
Pneumatic /Solid
OEM Service
Yes
Forklift Attachments
Paper Roll Clamp
Overhead Guard
Rain-Proof
Hydraulic System
Japan Shimadzu
Radiator
Copper
LED Warning Light
Yes
Seat
Toyota Seat
Mirrow
Wider-View Mirror
Transport Package
40hc
Specification
3431X2235X2500mm
Trademark
SNSC
Origin
China
HS Code
84272090
Production Capacity
6000 Piece/Year
Product Description
Product detail:
| Engine | China Xichai & Japanese 6BG1 Engine |
| Transmission | Electric hydraulic automatic transmission |
| Mast | standard duplex 3m mast(3m-6m duplex or triplex mast are optional) |
| Tires | Air tires (solid tires are optional) |
| Forks | standard 1070mm forks, fork extension are optional |
| Seat | Toyota seat with shock absorption function |
| Other configuration | Reverse buzzer,working light Rear view mirrors, tool box |
| Attachment | side shifter, fork positioner, all kinds of clamps such as bale clamp, paper roll calmp, etc. |
| Montacarga 5 Ton | |||||||
| Specifications | Unit | FD50 | FD60 | FD70 | |||
| 1 | Features | Power type | | - | Diesel | Diesel | Diesel |
| 2 | Rated load | | kg | 5000 | 6000 | 7000 | |
| 3 | Load center | | mm | 600 | 600 | 600 | |
| 4 | Lifting Height | | mm | 3000 | 3000 | 3000 | |
| 5 | Free lifting height | | mm | 203 | 208 | 218 | |
| 6 | Fork size | LxWxT | mm | 1220X150X55 | 1220X150X60 | 122X150X70 | |
| 7 | Mast Tilt Angle | Front/Rear | ° | 6/12 | 6/12 | 6/12 | |
| 8 | Min. Turning Radius | | mm | 3250 | 3370 | 3370 | |
| 10 | Min. Ground Clearance | Mast | mm | 200 | 200 | 200 | |
| 11 | Overhear Guard Height | | mm | 2460 | 2460 | 2460 | |
| 12 | Front Overhang | | mm | 610 | 615 | 625 | |
| 14 | Performances | Max. Travelling Speed | loaded | Km/h | 26 | 26 | 26 |
| 15 | Max. Lifting Speed | loaded/empty | mm/s | 370/450 | 370/450 | 370/450 | |
| 16 | Max. Traction Force | loaded | KN | 51.4 | 51.4 | 51.4 | |
| 17 | Max. Climbing Ability | | ° | 20 | 20 | 20 | |
| 18 | Dimension | Overall Length | without fork | mm | 3431 | 3431 | 3466 |
| 19 | Overall Width | | mm | 2235 | 2235 | 2235 | |
| 20 | Mast Lowered Height | | mm | 2500 | 2500 | 2500 | |
| 21 | Mast Extended Height | | mm | 4417 | 4417 | 4417 | |
| 22 | Chassis | Tyre | Front | - | 8.25-15-14PR | 8.25-15-14PR | 8.25-15-14PR |
| 23 | Rear | - | 8.25-15-14PR | 8.25-15-14PR | 8.25-15-14PR | ||
| 24 | Wheel Base | | mm | 2250 | 2250 | 2250 | |
| 25 | Wheel Thread | Front/Rear | mm | 1470/1700 | 1470/1700 | 1470/1700 | |
| 26 | Weight(without load) | | kg | 7980 | 8640 | 9340 | |
| 27 | Powertrain | Battery | | V/Ah | (12/90)X2 | (12/90)X2 | (12/90)X2 |
| 28 | Engine | Model | - | CY6102BG6 | CY6102BG6 | CY6102BG6 | |
| 29 | Rated Power | KW/r.p.m | 81/2500 | 81/2500 | 81/2500 | ||
| 30 | Rated Torque | N.m/r.p.m | 353/1700 | 353/1700 | 353/1700 | ||
| 31 | No. of cylinder | - | 6 | 6 | 6 | ||
| 32 | Bore x Stroke | mm | 102 x 118 | 102 x 118 | 102x118 | ||
| 33 | Displacement | | L | 5.785 | 5.785 | 5.785 | |
| 34 | Fuel Tank Capacity | | L | 140 | 140 | 140 | |
| 35 | Transmission/Shift | | - | 1/1 Automatic transmission | | ||
| 36 | Operation Pressure | | MPa | 20 | 20 | 20 | |
Successful Cases
Montacarga 5 Ton exported to Algeria
with Japan 6BG1 engine
duplex 3m mast
duplex 3m mast
Montacarga 5 Ton exported to Peru
with China Xichai 6110 engine
duplex 3m mast & fork positioner
Montacarga 5 Ton exported to Morocco
with Japan 6BG1 engine
triplex 6.5m mast & side shift
triplex 6.5m mast & side shift
Company file
We are top 3 in Chinese fork lifter manufactures and top 20 in the world,over 500 employees,30,000 units forklift truck production capacity per year,5000 sets export volume,our R&D research is in Britain, and we invested 600 million in forklift factory, use dvanced equipment, eg: welding robot and others to realize over 95% automatic production line.
Guaranty time:
12 months (which begins from the forklift arrived destination port date) or 2000 working hours, whichever comes first.
SNSC Forklifts have strict quality control system. Although strict quality control has been carried out during the production
12 months (which begins from the forklift arrived destination port date) or 2000 working hours, whichever comes first.
SNSC Forklifts have strict quality control system. Although strict quality control has been carried out during the production
process, to ensure our customers can receive high performance forklifts, all of our forklifts will be tested again before
delivery.
Our quality inspection is divided into indoor inspection and outdoor inspection. Indoor testing includes braking
performance, the inclination angle of mast, detection of chassis oil leakage, counterweight, etc. Outdoor testing includes
loading, lifting, tilting, turning, climbing, etc.
What kinds forklift we are selling:
1. Diesel Forklift Truck Range from 1 to 10tons; (FD30,FD35,FD40,FD45,FD50,FD60,FD70)
2. Electric Forklift Truck Range from 1.5 to 3.5tons; (FB15, FB20, FB25, FB30, FB35)
3. LPG & Gasoline Forklifts Range from 1.5 to 3.5tons; (FL15, FL20, FL25, FL30, FL35)
4. Warehouse Logistic Forklift 1 to 3tons Reach Truck / Pallet Truck / Stacker ;
5. 4X4 & 2x4 rough terrain forklift
We are dedicated to providing forklift VIP solution to meet all kinds of work condition which means SNSC forklift can be
customized. For example, if your want move forks from left to right automatically without moving forklift, we suggest you side shifter. if you want to adjust fork's distance, we suggest fork positioner. If your working environment is very cold or rainy, we suggest you fully closed cabin with opening windows. And all kinds of attachments, such as paper roll clamp, bale clamp, block clamp, carton clamp, double forks and so on,
We are dedicated to providing forklift VIP solution to meet all kinds of work condition which means SNSC forklift can be
customized. For example, if your want move forks from left to right automatically without moving forklift, we suggest you side shifter. if you want to adjust fork's distance, we suggest fork positioner. If your working environment is very cold or rainy, we suggest you fully closed cabin with opening windows. And all kinds of attachments, such as paper roll clamp, bale clamp, block clamp, carton clamp, double forks and so on,
Package and delivery:
Package with Tool Box, Forklift Catalogue, Gloves and Forklift Operation and Maintenance Manuals, Fork Sleeves and Spare Parts together.
Packaging&Shipping:
Nude package, fixed by Triangle iron Wedge with Flexible packing tape in container.
For Montacarga 5 Ton , 1*40'HC - 3 Units
